Descripción

Key Specification

Operating Voltage

3.14 V to 3.46 V

Max. Power Consumption

1.5 W

Operating Temperature

0°C to 70°C (32°F to 158°F)

Storage Temperature

–40°C to +85°C (–40°F to +185°F)

Operating Humidity

5ï¼… to 85ï¼…

Tx Wavelength

1480 nm to 1500 nm

Rx Wavelength

1290 nm to 1330 nm

Tx Power

3 to 7 dBm

Rx Power

–32 to –12 dBm

Weight

0.035 kg (0.08 lbs.)

Receiver Sensitivity

–32 dBm

Tx Rate

1.25 Gbps
